Crown CWL309MJ-Plus
★★★★★
5.0 (2)- ✔ Authentic Korean lever used by Tekken players
- ✔ Gersung microswitches for fast, tactile inputs
- ✔ Smooth bat-top control for wavedashing and KBD
- ✔ Includes 16mm and 16.2mm actuators for tuning
- ✔ Authentic Korean lever used by Tekken players
- ✔ Gersung microswitches for fast, tactile inputs
- ✔ Smooth bat-top control for wavedashing and KBD
- ✔ Includes 16mm and 16.2mm actuators for tuning
Available Colours
Compatibility
- Fits most Korean lever compatible fightsticks
- Compatible with Qanba Obsidian, Hori Fighting Edge and custom builds
- Requires 35mm mounting hole
- 5-pin harness connection
£28.99
Choose your colour
Select a variant to continue
Quantity
1
In stock • ships next working day
Genuine arcade parts
Secure checkout
Overview
The CWL-309MJ is a high-end Korean arcade joystick designed for competitive fighting-game use. It features a low-profile collar, a silicone-rubber tension grommet instead of a traditional spring, and premium microswitches for very fast return to neutral and fluid 360° movements
Specifications
- Model
- CWL-309MJ
- Size / Mounting
- Standard arcade lever, low-profile collar (~35 mm) for Japanese S-plate mount and Korean mounting compatibility
- Tension Grommet
- Silicone rubber grommet – ST30 as default (other options: ST25, ST35)
- Actuators Included
- Two actuators (approx. 16.0 mm and 16.2 mm outer diameter)
- Microswitches
- Gersung GSM-V1623A3 or GSM-V1603A3HM microswitches
- Handle / Grip
- Bat-top style (non-screwable handle moulded on shaft)
- Panel Compatibility
- Fits metal control panels, Japanese & Korean “fight-stick” style mounts
- Connector Type
- Spade terminal on each microswitch (.187″ quick-connect) or optional 5-pin harness conversion
- Weight
- Approx. 286 g (for ST30 version)
- Manufactured In
- South Korea
- Ideal Use
- Competitive fighting games (e.g., Tekken, The King of Fighters) because of fast return and precise movement
- Color / Variant Options
- Multiple color variants of the handle and mounting plate (black, white, red, yellow, blue, violet, etc)
